Epson EB-X51 Service Manual

EB-E01 series INTERNAL USE ONLY
SEIKO EPSON 5 Revision A
SAFETY INSTRUCTIONS
The precautionary measures itemized below should be fully understood when
performing repair and maintenance procedures.
When disassembling/assembling, be sure to turn off the power
switch and pull out the power cable from the projector beforehand.
Be extremely careful about the current-carrying part during a test
operation, signal measurement or any other situations that is
necessary to perform the repair/maintenance work with the power
turned on and the cover removed.
Take off the things made of metal (such as a wrist watch, cuff
buttons, rings, tie pin, etc.) which may come in contact with the
parts inside the projector.
Do not touch the lamp assy. or the parts around it. They are
extremely hot even after completing the cooling down operation,
and may cause a burn injury. Therefore, leave the unit until it
becomes cool enough before performing maintenance work.
Never let the safety devices mounted in this product inactivated,
modify the safety devices or replace them with the ones that are not
designated for any reason whatsoever. (Such actions may endanger
the projector's safety operation and may result in a fire or serious
injury.)
Never modify the product for any reason whatsoever. (Except for a
case that is under the instructions to do so. In such a case,
understand the instructions thoroughly in advance and perform
modification appropriately.)
Never peer through the projection lens during repair/maintenance
work when the power is on. (Such an action may cause a visual
disability because of a very strong light emission.)
Never use a deformed plug or a damaged power cable to this
product. If any deformations or damages are found on the power
cable or plug section, replace it with a new specified power cable.
Never use the air blowers that contain flammable gas in repair/
maintenance work.
Never use or replace with any service parts that is not specified by
EPSON.
Do not disassemble any parts or components not specified in this
manual.
Do not apply any shock or vibration. (Otherwise, misalignment of
the optical parts inside the engine may cause irregular reflection of
the light and may result in burn (smoke) or damage to the internal
parts.)
Do not touch any parts such as inorganic polarizers that are
instructed not to.
