Epson EB-X51 Service Manual

EB-E01 series Troubleshooting INTERNAL USE ONLY
SEIKO EPSON 56 Revision A
*1 EB-FH52/992F, EH-TW750
*2 EB-FH52/992F/W52, EH-TW750
*3 EB-E01/X06/W06/E10/X51/W51/W52
*4 EB-FH52/972/982W/992F/118, PL 119W
*5 EB-FH06/E20/X49/W49, EH-TW740/TW750
CN2200 Auto Iris Assy Auto Iris Auto Iris Error
The power can turn on and Power LED lights blue. When pressing the power button,
initialization starts but instantly the projector changes to the Auto Iris Error mode. The
error message in Auto Iris is displayed on the screen, and it advises the user to turn off
the power and to contact the Epson Service. When pressing the power button, the LEDs
indicate the warning and after a certain period of cooling, the projector turns into the
abnormal stand-by status. The LED Indicator’s warning display continues until
unplugging the AC cable.
P.60
CN700*
3
Speaker (2W)
--- ---
When pressing the power button, initialization starts normally and the projection starts.
However, no sound is output from the speaker even if the audio input is applied. Audio
controller on screen display appears, but no sound is output from the speaker even if
the audio input is applied.
P.62
CN701*
4
Speaker (16W)
CN702*
5
Speaker (5W)
Connector
No.
Destination
Error Information
Phenomenon Reference
Error Name/
Device Name
Name

Epson EB-X51 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2500 ANSI lumens
RMS rated power	2 W
Number of built-in speakers	1
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Built-in display	No
Focus	Manual
Offset	8 %
Throw ratio	1.48 - 1.77:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.79
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	4035 g
