Preparing
22
Connecting a Computer
To project images from a computer, connect the computer using one of the following methods.
Computers with an RGB output port
Computers with an HDMI output port
To prevent the weight of the HDMI cable disconnecting it from the port, make sure you secure it to the cable
holder with the HDMI cable clamp.
Connecting External Devices
Connecting to Trigger out 1/Trigger out 2 ports
To connect external devices such as motorized screens, connect a mini-jack stereo cable (3.5 mm).
When set to on, a signal (12 V DC) is output from this port to communicate the projector's status (on/off) to
connected devices such as electric screens.
c
When using the Trigger out 1/Trigger out 2 ports, set Trigger Out 1/Trigger Out 2.
s
Settings -
Operation - Trigger Out 1/Trigger Out 2 p.91
