Epson EH-TW5700 User Manual

Contents
4
Adjusting the Color Temp................. 38
Adjusting the RGB (Offset and Gain).........38
Adjusting Hue, Saturation, and Brightness.....39
Adjusting the Gamma ...................40
Select and adjust the correction value . . . . . . 40
Adjust using the gamma adjustment graph
.................................. 41
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 42
Saving a Memory ....................... 42
Loading, Deleting, and Renaming a Memory
.................................... 43
Useful Functions
Enjoying 3D Images .................. 44
Preparing to View 3D Images .............. 44
If the 3D image cannot be viewed .........44
Using 3D Glasses ....................... 45
Notifications Regarding Viewing 3D Images . . . . 45
Using the HDMI Link Function ........ 47
HDMI Link Function ..................... 47
HDMI Link Settings ......................47
Connecting ........................... 48
Configuration Menu
Configuration Menu Functions ........ 49
Configuration Menu Operations ............ 49
Configuration Menu Table................ 50
Image menu ........................50
Signal menu ........................ 51
Settings menu ....................... 52
Extended menu ...................... 54
Info menu .......................... 55
Reset menu ......................... 56
Troubleshooting
Problem Solving ..................... 57
Reading the Indicators ................... 57
Indicator status during an error/warning....57
Indicator status during normal operation . . . . 59
When the Indicators Provide No Help........60
Check the problem .................... 60
Problems relating to images ............. 61
Noise problems ...................... 64
Problems when projection starts .......... 64
Problems with the remote control ......... 65
Problems with the control panel .......... 65
Problems with 3D .................... 65
Problems with HDMI ..................66
Bluetooth device problems .............. 67
Problems with a streaming media player . . . . 67
Maintenance
Maintenance ........................ 69
Cleaning the Parts ...................... 69
Cleaning the air filter .................. 69
Cleaning the main unit ................. 70
Cleaning the lens ..................... 71
Replacement Periods for Consumables.......71
Air filter replacement period ............. 71
Lamp replacement period .............. 71
Replacing Consumables .................. 72
Replacing the air filter .................72
Replacing the lamp ...................72
Resetting lamp hours .................. 74
Disconnecting a Streaming Media Player......76
Appendix
Optional Accessories and
Consumables ........................ 77
Optional Items ......................... 77
Consumables .......................... 77
Supported Resolutions ............... 78
PC .................................. 78
SD ................................. 78
HD .................................78
3D ................................. 79
Specifications ....................... 81
EH-TW5820/EH-TW5700 .................. 81
Appearance ......................... 83

Epson EH-TW5700 Specifications

General

Heat dissipation	1009.8 BTU/h
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	2.71 - 2.61 m
Projection technology	3LCD
Contrast ratio (typical)	35000:1
Screen size compatibility	34 - 332 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Placement	Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	-
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4500 h
Service life of light source (economic mode)	7500 h
Focus	Manual
Focal length range	16.9 - 20.28 mm
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	297 W
Video color modes	Bright cinema, Cinema, Dynamic, Natural
DVI port	No
HDMI version	1.4
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	315 mm
Width	309 mm
Height	122 mm
Weight	3600 g
