Epson EH-TW9100W User Manual

Appendix
100
Specifications
Product name
EH-TW9100W/EH-TW8100W EH-TW9100/EH-TW8100
Appearance (not including adjustable foot)
466 (W) x 140 (H) x 395 (D) mm
Panel Size
0.74" wide
Display method
Polysilicon TFT active matrix
Resolution
1920 (W) x 1080 (H) x 3
Scanning Fre-
quency
Digital
Pixel Clock: 13.5 - 148.5 MHz
Horizontal: 15.6 - 67.5 kHz
Vertical: 24 - 60 Hz
Analog
Pixel Clock: 13.5 - 157.5 MHz
Horizontal: 15.6 - 91.2 kHz
Vertical: 50 - 85 Hz
Focus adjustment
Manual
Zoom adjustment
Manual (approx. 1 to 2.1)
Lamp (light source)
UHE lamp 230 W, Model No.: ELPLP69
Power supply
100 to 240 V AC ±10%, 50/60 Hz, 3.7 - 1.6 A
Power con-
sumption
100 to 120 V area
Operating: 357 W
Standby power consumption: 0.30 W
Standby power consumption: 7.5 W
*
220 to 240 V area
Operating: 340 W
Standby power consumption: 0.39 W
Standby power consumption: 8.4 W
*
Operating altitude
Altitude 0 to 2286 m
Operating temperature
+5 to 35°C (No condensation)
Storage temperature
-10 to +60°C (No condensation)
Mass
Approx. 8.6 kg Approx. 8.4 kg
Connectors
Component port x 1, 3RCA pin jack
PC port x 1, Mini D-Sub15-pin (female) blue
HDMI port x 2, HDMI
For HDCP, For CEC signals, Deep Color
Video port x 1, RCA pin jack
RS-232C port x 1, D-sub 9-pin (male)
Trigger out port x 1, 3.5 mm mini jack
*
When using the WirelessHD Transmitter with EH-TW9100W/EH-TW8100W, and the following conditions are
satisfied
Settings - WirelessHD - WirelessHD - On
Settings - HDMI Link - Power On Link is set to Bidirectional or Device -> PJ
s p.73

Epson EH-TW9100W Specifications

General

RS-232 ports	1
Matrix size	0.74 \
White light output	2400 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.9 - 19.2 m
Projection distance (wide)	0.9 - 9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	23 - 47 mm
Aperture range (F-F)	2 - 3.17
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	22 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.39 W
Power consumption (typical)	340 W
Power consumption (economy mode)	287 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	2244 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	395 mm
Width	466 mm
Height	140 mm
Weight	8400 g
Package depth	573 mm
Package width	531 mm
Package height	350 mm
Package weight	13050 g
