Useful Functions
47
Pairing 3D Glasses
To create 3D images, the 3D Glasses need to be paired with the projector.
Press the [Pairing] button on the 3D Glasses to start pairing. See the User's Guide for the 3D Glasses for more
information.
c
For 3D Glasses that have not been used, pairing is performed when the 3D Glasses are turned on. You
do not need to perform pairing if 3D images can already be viewed correctly.
Once pairing has been performed, you can view 3D images the next time the devices are turned on.
You can perform pairing within a range of three meters from the projector. While pairing is being
performed, make sure you stay within a range of three meters from the projector. Otherwise, pairing
may not be performed correctly.
If synchronization cannot be performed within 30 seconds, pairing is automatically canceled. When
pairing is cancelled, 3D images cannot be viewed because pairing fails.
Wearing the 3D Glasses
a
Turn on the 3D Glasses by sliding the
[Power] switch to On.
The indicator turns on for several seconds,
and then turns off.
b
Put on the 3D Glasses and enjoy the
show.
c
When you have finished using the
3D Glasses, turn them off by
sliding the [Power] switch to Off.
If the 3D Glasses are not used for
at least 30 seconds, they turn off
automatically. To turn the 3D
Glasses back on, slide the
[Power] switch to Off, and then
slide it back to On.
You need more pairs of optional
3D Glasses if more than one
person will be viewing the 3D
image.
s p.97
