Epson EH-TW9100W User Manual

Contents
4
Frame Interpolation ..................... 39
Super-resolution .......................40
Image Processing ....................... 40
Selecting the Color Gamut (EH-TW9100W/EH-
TW9100 Only) ......................... 41
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 42
Saving Function ........................ 42
Saving a Memory ....................... 42
Loading a Memory ......................43
Deleting a Saved Memory ................. 43
Renaming a Memory .................... 43
Useful Functions
Enjoying 3D Images .................. 45
Setting 3D Images ...................... 45
If the 3D image cannot be viewed .........45
Using 3D Glasses ....................... 46
Charging the 3D Glasses ................46
Pairing 3D Glasses ....................47
Wearing the 3D Glasses ................47
Range for Viewing 3D Images .............. 48
Warnings Regarding Viewing 3D Images......49
Converting 2D Images to 3D and Viewing.....52
Connecting with WirelessHD (EH-
TW9100W/EH-TW8100W Only) . . . . . . . . 53
Installing the WirelessHD Transmitter........53
WirelessHD Transmitter part names ........ 54
Setting the WirelessHD Transmitter ........ 55
Projecting Images ......................56
WirelessHD Settings Menu................57
WirelessHD Transmission Range ............ 58
Useful Functions of the WirelessHD Transmitter
.................................... 59
Switching the target image .............. 59
Switching the image source .............60
Remote control operating range .......... 62
Using the HDMI Link Function ........ 63
HDMI Link Function ..................... 63
HDMI Link Settings ...................... 63
Device Connections ..................... 64
Changing Between Two Types of
Images .............................. 65
Types of Screen that can be Displayed
Simultaneously ........................ 65
Projecting on a Split Screen ...............65
Starting split screen display.............65
Changing the split screen settings ......... 66
Configuration Menu
Configuration Menu Functions ........ 67
Configuration Menu Operations............67
Configuration Menu Table................68
Image menu ........................68
Signal menu ........................ 70
Settings menu ....................... 73
Extended menu ...................... 75
Memory menu ....................... 76
Info menu .......................... 77
Reset menu ......................... 77
Split Screen menu .................... 78
Troubleshooting
Problem Solving . .................... 79
Reading the Indicators ................... 79
Indicator status during an error/warning....79
Indicator status during normal operation . . . . 80
When the Indicators Provide No Help........81
Check the problem .................... 81
Problems relating to images ............. 82
Problems when projection starts ..........86
Problems with the remote control ......... 86
Problems with 3D .................... 87
Problems with HDMI ..................87
Problems with WirelessHD (EH-TW9100W/
EH-TW8100W only) ................... 88
Maintenance
Maintenance ........................ 90
Cleaning the Parts ...................... 90
Cleaning the air filter .................. 90
Cleaning the main unit ................. 91

Epson EH-TW9100W Specifications

General

RS-232 ports	1
Matrix size	0.74 \
White light output	2400 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.9 - 19.2 m
Projection distance (wide)	0.9 - 9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	23 - 47 mm
Aperture range (F-F)	2 - 3.17
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	0
Noise level	- dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	22 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.39 W
Power consumption (typical)	340 W
Power consumption (economy mode)	287 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Pallet width	800 mm
Pallet height	2244 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	395 mm
Width	466 mm
Height	140 mm
Weight	8400 g
Package depth	573 mm
Package width	531 mm
Package height	350 mm
Package weight	13050 g
