Technical Specifications
General
CCD 1/3 inch (848,676 progressive scan)
Resolution 1024 × 768 pixels
(Effective resolution, or overscan, is
1034 × 779 pixels)
Lens F=2.8, f=4.7 to 84.6 mm
Frame speed 20 frames per second
Shooting area 13.7 × 10.2 in. (350 × 260 mm) max.
1.0 × 0.8 in. (25 × 19 mm) min.
Limit of focus
adjustment 3.9 in. (100 mm) from the stage surface
using the close-up lens
1.6 feet (0.5 m) to infinity with the camera
positioned horizontally and without using
the close-up lens
Zoom 18× optical with double speed function
Focus Automatic/manual
Iris Automatic/manual
White balance Automatic/manual
Gamma selection ON (
γ=0.3/0.4/0.5/0.6/0.7/0.8/0.9)
OFF (
γ=1.0)
Image rotation 90°/180°/270°
Frequency selection 50 or 60 Hz
Video output NTSC or PAL
