Epson FX-2190IIN Network Guide

Contents
Copyrights
Trademarks
About this Manual
Marks and Symbols......................... 6
Descriptions Used in this Manual.............. 6
Operating System References.................. 6
Introduction
Manual Component........................ 8
Definitions of Terms Used in this Guide......... 8
Preparation
Flow of the Printer Settings.................. 10
Introduction of Printer Connection.......... 10
Server / Client Connection Settings.......... 11
Peer to Peer Connection Settings............ 11
Preparing Connection to a Network............ 11
Gathering Information on the Connection
Setting............................... 11
Printer Specifications.................... 12
Type of IP Address Assignment............. 12
Method for Setting Network Connection. . . . . . 12
Installing EpsonNet Config................ 13
Running EpsonNet Config................ 13
Connection
Connecting to the Network.................. 14
Connecting to LAN...................... 14
Assigning an IP Address Using EpsonNet
Config............................... 14
Connecting to the Network Using the Installer
.................................... 18
Function Settings
Web Config (Web Page for Device)............ 20
About Web Config...................... 20
Accessing Web Config.................... 20
Using the Print Functions................... 21
Requirement for Printing over a Network...... 21
Setting of the Printer Driver Using Server /
Client Connection....................... 21
Printer Driver Settings for Peer to Peer
Connection............................ 26
Security Settings
Security Settings and Prevention of Danger. . . . . . 28
Security Feature Settings.................. 29
Configuring the Administrator Password........ 29
Configuring the Administrator Password
Using Web Config...................... 29
Controlling Protocols and Services............. 30
Controlling Protocols.................... 30
SSL/TLS Communication with the Printer....... 34
About Digital Certification................ 34
Obtaining and Importing a CA-signed
Certificate............................. 35
Deleting a CA-signed Certificate............ 38
Updating a Self-signed Certificate........... 38
Encrypted Communication Using IPsec/IP
Filtering................................ 39
About IPsec/IP Filtering.................. 39
Configuring Default Policy................ 40
Configuring Group Policy................. 41
Configuration Examples of IPsec/IP Filtering
.................................... 46
Using SNMPv3 Protocol.................... 47
About SNMPv3......................... 47
Configuring SNMPv3.................... 48
Solving Problems
Checking the Log for Server and Network Device
...................................... 50
Printing a Network Status Sheet............... 50
Initializing the Network Settings.............. 50
Restoring the Network Settings from the
Printer............................... 50
Restoring the Network Settings using
EpsonNet Config....................... 50
Checking the Communication between Devices
and Computers........................... 51
Checking the Connection Using a Ping
Command. . . . . . . . . . . . . . . . . . . . . . . . .... 51
FX-890IIN/FX-2190IIN/FX-2175IIN Network Guide
Contents
2

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
