Epson FX-2190IIN Network Guide

Model name and/or IP address are not displayed on EpsonNet Config
Did you select Block, Cancel, or Shut down when a Windows security screen or a firewall screen was displayed?
If you select Block, Cancel, or Shut down, the IP address and model name will not display on EpsonNet Config or
EpsonNet Setup.
To correct this, register EpsonNet Config as an exception using Windows firewall and commercial security software. If
you use an antivirus or security program, close it and then try to use EpsonNet Config.
Is the communication error timeout setting too short?
Run EpsonNet Config and select Tools > Options > Timeout, and then increase the length of time for the
Communication Error setting. Note that doing so can cause EpsonNet Config to run more slowly.
Solving Problems for Advanced Security
Restoring the Security Settings
When you establish a highly secure environment such as IPsec/IP Filtering, you may not be able to communicate with
devices because of incorrect settings or trouble with the device or server. In this case, restore the security settings in
order to make settings for the device again or to allow you temporary use.
Disabling the Security Function from the Printer
You can disable IPsec/IP Filtering from the printer.
A
Make sure paper is loaded.
B
Press the Menu (Pitch and Tear Off/Bin) buttons until the printer beep once and the Menu lights (both the
Tear Off/Bin lights) turn on.
The printer enters the default-setting mode and prints a message prompting you to select the language for the
default-setting menu. The language which is underlined indicates the current setting.
C
If the language you want is not selected, press the ItemD (Font) button until the printout indicates the language
you want.
D
Press the Set (Tear Off/Bin) button to select the desired language.
E
If you want to print the current settings, press the Set button. If you want to bypass printing of the current
settings, press the ItemD button or the ItemU button.
The printer prints the first menu and the current value of the menu.
F
Press the ItemD button or the ItemU button to select the menu parameters of IPsec/IP Filtering. Press the Set
button to scroll through the values within the selected parameter until you find Off.
FX-890IIN/FX-2190IIN/FX-2175IIN Network Guide
Solving Problems
53

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
