Epson FX-2190IIN Network Guide

Note:
❏ Examples
IPv4:
https://192.0.2.111/
http://192.0.2.111/
IPv6:
https://[2001:db8::1000:1]/
http://[2001:db8::1000:1]/
❏ If the printer name is registered with the DNS server, you can use the printer name instead of the printer’s IP address.
❏ Not all menus are displayed when accessing Web Config via HTTP. To see all the menus, access Web Config via
HTTPS.
Related Information
& “SSL/TLS Communication with the Printer” on page 34
& “About Digital Certification” on page 34
Using the Print Functions
Enable to use the printer's print function.
Requirement for Printing over a Network
The following is required to print over a network. You can configure these settings using the printer driver and
functions of the operating system.
❏ Installing the printer driver
❏ Making the print queue to a computer
❏ Setting the port to a network
Setting of the Printer Driver Using Server / Client Connection
Set the printer to enable printing from a computer that was previously set as the print server, and share the printer.
Install the printer driver for both the server and the client on the print server. If the installer is used, setting of the
printer’s network or computer, installation of the driver, and making the print queue are performed automatically.
Setting Up Standard TCP/IP Ports - Windows
Set up the Standard TCP/IP port on the print server, and create the print queue for network printing.
A
Open the devices and printers screen.
❏ Windows 10/Windows Server 2016
Right-click the start button or press and hold it, and then select Control Panel > Hardware and Sound >
Devices and Printers.
FX-890IIN/FX-2190IIN/FX-2175IIN Network Guide
Function Settings
21

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
