PARTS
LISTS
3.3
FX-80
/
80
+ /
85
PRINTER
MECHANISM
COMPONENTS
ITEM
XEROX
#
EPSON
#
DESCRIPTION
1
84NS7
F315056000
HOME
POSITION
SENSOR
ASSEMBLY
2
116N29
F315054000
TERMINAL
BOARD
ASSEMBLY
3
26N35
B040302811
CUP
SCREW
4
140N274
F315060000
PRINTING
SIGNAL
SENSOR
BOARD
ASSEMBLY
5
7N36
F315052010
RIBBON
DRIVING
GEAR
6
84NS6
F315059000
CARRIAGE
MOTOR
ASSEMBLY
7
20N12
F303017000
BELT
DRIVEN
PULLEY
8
13N14
B210151490
BALLBEARING
9
9N52
F303005020
HEAD
LOCK
LEVER
SPRING
10
23N30
F315017020
FELT
RING
11
84N54
F315018000
CARRIAGE
ASSEMBLY
12
108N62
F315021130
RIBBON
MASK
13
84N58
F404100000
PRINT HEAD (FX-80)
130N101
F404110000
PRINT HEAD (FX-85)
14
23N6
F303014010
TIMING
BELT
A
15
20N13
F303018020
BELT
DRIVEN
PULLEY
FLANGE
16
20N34
F303018010
BELT
DRIVEN
PULLEY
17
84N46
F303020000
PLANETARY
LEVER
ASSEMBLY
18
9N54
B101252190
LEAF
SPRING
19
547N118
F303020020
PLANETARY
PINION
EPSON
PRINTERS
3-4
