PARTS
LISTS
3.10
FX-100/100
/185/286
COVERS AND ELECTRICAL COMPONENTS
(PARTI)
ITEM
XEROX
#
EPSON
# DESCRIPTION
1
101N107
Y44020S000
140N670
Y440212000A
140N918
Y44020500B
140N1313
Y440212200
FXBDBOARD (FX 100)*SEE NOTE 1
FXMB BOARD (FX 100
♦/185
W/SOLDERED CPU)
FMBD BOARD (FX100 W/CPU)
FXMM BOARD (FX
286)
FOR ILLUSTRATION OF CHIP LOCATIONS SEE SECTION
6.6
FOR IC
CHIP
PART
NUMBERS
AND
COMPATIBILITY
SEE:
TABLE
3-2
FOR
THE
FX-100
TABLE
3-4
FOR
THE
FX-lOO
+
TABLE
3-6
FOR
THE
FX-185
TABLE
3-7
FOR
THE
FX-286
TABLE
3-8
FOR
THE
FXEXT
BOARD
2
46N18
Y441590000
3
547N142
F011402411
4
547N235
Y441004001
5
3N71
Y440010001
3N197
Y440068001
M-3560
PRINTER
MECHANISM
CP
SCREW
LOWERCASE
PLATEN KNOB
(FX-100)
PLATEN KNOB (FX-185)
EPSON
PRINTERS
NOTE
1:
THE
MAIN
CIRCUIT BOARDS ARE SPARED SEPARATELY FROM THE CHIPS. USE THE
APPROPRIATE TROUBLESHOOTING PROCEDURE TO DETERMINE WHICH COMPONENT YOU
NEED
TO
REPLACE.
3-18
