PARTS
LISTS
3.11
FX-100/1001-/185/286
PRINTER MECHANISM COMPONENTS
(Parti)
ITEM
XEROX
#
EPSON
#
DESCRIPTION
1
28N16
8150300611
E-RING
2
28N19
8150300811
E-RING
3
28N17
8150300912
E-RING
4
11N12
F315021030
HEAD
ADJUSTMENT
LEVER
5
28N1S
8150350111
E-RING
6
9N99
F317013010
LEFT
PAPER
HOLDING
LEVER
SPRING
7
11N38
F304008030
PAPER
HOLDING
LEVER
SPRING
8
22N44
F317011010
PAPER
FEEDING
ROLLER
9
S47N156
F312008020
0-RING
10
24N1
F317014020
CARRIAG&SHAFT
11
9N100
F317013020
RIGHT
PAPER
HOLDING
LEVER
SPRING
12
9NS2
F303005020
HEAD
LOCK
LEVER
SPRING
13
23N30
F315017020
FELT
RING
14
84N54
F315018000
CARRIAGE
ASSEM8LY
15
57N4
F303001092
RI8B0N
MASK
16
130N38
F404300000
PRINT HEAD (FX
100)
130N102
F404120000
PRINT HEAD (FX
185)
130N117
F410100000
PRINT HEAD (FX
286)
17
7N35
F315021070
PAPER
FEEDING
REDUCTION
GEAR
18
9N59
F315062030
PAPER
FEEDING
SPRING
19
26N37
8040450812
CP
SCREW
20
84N55
F315064000
PULSE MOTOR ASSEM8LY (FX
100/185)
127N245
F328054000
PULSE
MOTOR
ASSEMBLY (FX
286)
21
29N12
8130103216
SPRING
PIN
EPSON
PRINTERS
ITEM
XEROX#
EPSON
#
DESCRIPTION
22
7N34
F304004010
PLATEN
GEAR
23
9N56
8101251490
LEAF
SPRING
24
110N56
A170202502
REED
SWITCH
25
9N20
F303007020
PAPER
EMPTY
LEVER
SPRING
26
28N18
8150300311
E-RING
27
90N31
F317004000
PLATEN
3-22
