PARTS
LISTS
3.18
RX-100/100-1- PRINTERMECHANISM COMPONENTS
(Parti)
ITEM
XEROX
#
EPSON
#
DESCRIPTION
1
28N19
B150300811
E •
RING
2
26N35
8040301311
CP
SCREW
3
20N13
F303018020
BELT
DRIVEN
PULLEY
FLANGE
4
20N34
F303018010
BELT
DRIVEN
PULLEY
5
547N118
F303020020
PLANETARY
PINION
6
7N7
F303014020
RIBBON
DRIVING
GEAR
7
26N37
804050812
CP
SCREW
8
140N1071
F320053000
TERMINAL
BOARD
ASSEMBLY
9
130N6
F304059000
PTS
SENSOR
BOARD
ASSEMBLY
10
127N194
F320056000
CARRIAGE
MOTOR
11
20N12
F303017000
BELT
DRIVEN
PULLEY
ASSEMBLY
12
23N7
F310057020
TIMING
BELT
EPSON
PRINTERS
3-36
