Epson L565 Service Manual

Confidential
Disassembly/Reassembly Overview 26
L565/L566 Series Revision A
PF Roller Unit 24:35 5:51 30:26
PF Motor Assy
25:26 1:08 26:34
Frame Base 26:07 6:53 33:00
Ink Supply Tank Assy 4:04 --- 4:04
Top Cover
0:10 --- 0:10
Bottom Cover
1:44 --- 1:44
Left Cover
2:34 --- 2:34
Right Cover
2:07 --- 2:07
Ink Supply Tank (Magenta)
4:11 --- 4:11
Ink Supply Tank (Yellow)
4:11 --- 4:11
Ink Supply Tank (Cyan)
4:11 --- 4:11
Ink Supply Tank (Black)
4:11 --- 4:11
Cap Tank
0:22 --- 0:22
Cover Tube Tank
0:55 --- 0:55
Guide Tube Tank
1:06 --- 1:06
Ink Supply Tank Tube Assy
3:30 --- 3:30
Cover Joint
2:39 --- 2:39
Ink Supply Tube Guide 1st
0:22 --- 0:22
Ink Supply Tube Guide 2nd
1:18 --- 1:18
Joint
2:20 --- 2:20
Tube Pressing Plate
0:30 --- 0:30
Ink Supply Tube Assy
2:11 --- 2:11
Adapter
1:49 --- 1:49
Tube Guide Sheet
1:39 --- 1:39
Tube Guide Sheet Sub
0:30 --- 0:30
Adapter Cover
0:37 --- 0:37
Tube Cover
0:22 --- 0:22
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson L565 Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	9.2 ppm
Print speed (color, normal quality, A4/US Letter)	4.5 ppm
Maximum copy resolution	- DPI
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	100 pages
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Indonesia
Maximum duty cycle	- pages per month
Paper input type	Paper tray
Total input capacity	30 sheets
Total output capacity	100 sheets
Photo paper sizes	10x15, 13x18 cm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C6
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP
Standard interfaces	USB 2.0
Internal memory	- MB
Sound pressure level (copying)	38 dB
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	1.6 W
Power consumption (average operating)	11 W
Sustainability certificates	ENERGY STAR
Pallet width	800 mm
Pallet height	1320 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	563 mm
Package width	465 mm
Package height	315 mm
Package weight	9060 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	377 mm
Width	484 mm
Height	226 mm
