Epson L565 Service Manual

Confidential
Disassembly/Reassembly Overview 23
L565/L566 Series Revision A
2.1.4 Standard Operation Time for Servicing the Product
The following are the standard operation time for servicing the product. This standard operation time was
determined with the MTTR result measured using the prototype of L565/L566 Series which have the most
functions. For other models described in this manual, perform the repair work referring to this standard operation
time though the time varies due to the structural difference between models.
The underlined parts/units are supplied as After Service Parts.
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
Housing Rear 0:36 --- 0:36
Paper Support
0:09 --- 0:09
Paper Support Sub
0:23 --- 0:23
Tray Front Assy
0:15 --- 0:15
Tray Front 0:15 --- 0:15
Tray Front Support 0:22 --- 0:22
Paper Guide Front Unit
0:49 7:44 8:33
Waste Ink Pad Assy
0:42 0:45 1:27
Paper Back Lever
1:52 --- 1:52
Retard Roller Assy
2:00 0:47 2:47
FFC Cover Outer 0:26 --- 0:26
Holder Board
0:56 --- 0:56
Printhead
2:20 17:39 19:59
ADF Paper Guide Cover Assy
0:25 --- 0:25
ADF Cable Cover 0:27 --- 0:27
Paper Support Cover
0:06 --- 0:06
Document Mat 0:13 --- 0:13
ADF/Scanner Unit 2:46 2:52 5:38
ADF Unit
3:32 2:52 6:24
ADF Hinge Left 5:28 --- 5:28
ADF Document Support
7:06 --- 7:06
ADF Hinge Right 3:53 --- 3:53
Cover Gear Assy 4:29 --- 4:29
Bevel Gear Shaft
4:34 --- 4:34
Combination Gear 24.9.6
4:33 --- 4:33
ADF Frame Assy 5:04 --- 5:04
ADF Front Frame 6:00 --- 6:00
Spur Gear 20.4 / 25.8 6:04 --- 6:04
ADF Driven Gears 6:42 --- 6:42
ADF Upper Frame Assy 6:44 --- 6:44

Epson L565 Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	9.2 ppm
Print speed (color, normal quality, A4/US Letter)	4.5 ppm
Maximum copy resolution	- DPI
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	100 pages
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Indonesia
Maximum duty cycle	- pages per month
Paper input type	Paper tray
Total input capacity	30 sheets
Total output capacity	100 sheets
Photo paper sizes	10x15, 13x18 cm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C6
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP
Standard interfaces	USB 2.0
Internal memory	- MB
Sound pressure level (copying)	38 dB
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	1.6 W
Power consumption (average operating)	11 W
Sustainability certificates	ENERGY STAR
Pallet width	800 mm
Pallet height	1320 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	563 mm
Package width	465 mm
Package height	315 mm
Package weight	9060 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	377 mm
Width	484 mm
Height	226 mm
