Epson L565 Service Manual

Confidential
Troubleshooting Fatal Error Code List 14
L565/L566 Series Revision A
1.3.2 Printer Fatal Error Code
This section describes the fatal error code and the possible cause for this product.
Table 1-3. Fatal Error List (Printer)
Error type
Error
code
Error name Possible cause
ADF/Scanner
0x10 HP detection failure
• CIS Unit failure
• Scanner Housing failure
• Main Board failure
• Insufficient grease
• Foreign object
• FFC for CIS failure / FFC for CIS connection failure
0x14 Measurement error
• Scanner drive mechanism was overloaded.
• Insufficient grease
• Foreign object
• Lack of gears
• Deformation of the shaft
0x20 LED light failure
• CIS Unit failure
• Main Board failure
0x51 Auto judge Fatal Error 1
---*
0x52 Auto judge Fatal Error 2
0x53 Auto judge Fatal Error 3
0x54 Auto judge Fatal Error 4
0x55 Auto judge Fatal Error 5
Printer
0x60 Home position
• Carriage overload error (paper jam/foreign object)
• Deformation of the Main Frame
• Ink system failure
• CR Motor failure
• Deformation of the Front Frame
• CR Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Cable disconnection
0x63
Ink cartridge replacement timing contact
detection error (Power off)
• Paper jam
• Foreign object
• Deformation of the Main Frame
0x64 Paper-Jam cancelation disable error
• Paper jam
• Foreign object
0x81 PIS environmental error • Diffused light
0x82 PIS continuous reflected light error
• PIS failure
• Main Board failure
• Diffused light
0x83 PIS No reflected light error • PIS failure (installation posture, contamination)
0x84 PIS shift length error
• Home position gap
• Diffused light
0x87 PIS Empty Jig error • PIS failure (installation posture, contamination)
0x88 Excessive Light error
• PIS failure
• Main Board failure
• Diffused light
0x89 Insufficient Light error
• PIS failure (installation posture, contamination)
• Main Board failure
• Ink cartridge failure
0x8F EEPROM verify error (by command)
---*
0x9A Circuit error (include blowout of a fuse)
• Main Board failure
0x9B Transistor temperature error

Epson L565 Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	9.2 ppm
Print speed (color, normal quality, A4/US Letter)	4.5 ppm
Maximum copy resolution	- DPI
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	100 pages
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Indonesia
Maximum duty cycle	- pages per month
Paper input type	Paper tray
Total input capacity	30 sheets
Total output capacity	100 sheets
Photo paper sizes	10x15, 13x18 cm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C6
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP
Standard interfaces	USB 2.0
Internal memory	- MB
Sound pressure level (copying)	38 dB
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	1.6 W
Power consumption (average operating)	11 W
Sustainability certificates	ENERGY STAR
Pallet width	800 mm
Pallet height	1320 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	563 mm
Package width	465 mm
Package height	315 mm
Package weight	9060 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	377 mm
Width	484 mm
Height	226 mm
