2016/09/02
Revision: 1 Page: 34
5.1.12 Set absolute vertical print position (extended) ESC (V nL nH m1 m2 m3 m4
ESC (V nL nH m1 m2 m3 m4 Ver 2.00
[Name] Set absolute vertical print position(extended) [Operation]
[Format] 1BH, 28H, 56H, nL, nH, m1, m2, m3, m4
[Range of Definition] nL=04H, nH=00H
(Vertical position set) = (mL + mH x 256) x (units set)
0 <= (m4*1000000H+ m3*10000H+m2*100H+m1)×1440 <= 1FFFFFFFH
(absolute vertical print position value)
[Function] 1) The printing position in the Y direction is set to a position spaced in the positive direction
by (m4*256*256*256 +m3*256*256 + m2*256 + m1) x (absolute vertical print position
value) from the Y axis of the position management coordinate system.
2) If the printing position in the Y direction has been set by this command to a non-printable
area, then the paper is ejected. The position management coordinate system is set to the
next page. In addition, the printing position in the Y direction is reset to the origin upon the
Y axis of the new position management coordinate system.
3) Settings made in the negative direction are ignored.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
None
[Setting] Commands that change the effects of this command.
None
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
The absolute vertical position value is set by the ESC( U commands.
The range of unprintable areas are set by the ESC( c, ESC N and ESC O commands.
The relative vertical position setting value, the non-printable area and the printing position in the
Y direction are reset to their initial states by the ESC @ and ESC (G commands.
