2016/09/02
Revision: 1 Page: 44
5.1.21 Set the raster image resolution ESC (D nL nH rL rH v h
ESC (D nL nH rL rH v h Ver 1.00
[Name] Set the raster image resolution
[Format] 1BH, 28H, 44H, nL,nH, rL, rH, v,h
[Range of Definition]
nL=04H, nH=00H
0 <= v <= 127
0 <= h <=127
[Function]
1) Sets the raster image resolution ( ESC i ).
Vertical resolution : ( rH*256 + rL ) / v dpi
Horizontal resolution : ( rH*256 + rL ) / h dpi
2) Available resolutions are : 120, 360, 720dpi
3) Following parameters are supported.
These printers doesn’t have printer microweave mode.
1.
In case of microweave mode off
1. Case of Driver microweave mode
Case of Driver microweave mode Black Mode
Mode ESC ( D ESC i ESC(e Used Nozzle number
(H x V) h / r v / r mH*256+mL
n2
360x180
4/1440
12/1440
180 11h/12h/13h 180Nozzles
Case of Driver microweave mode Color Mode
Mode ESC ( D ESC i ESC(e Used Nozzle number
(H x V) h / r v / r mH*256+mL
n2
360x180
4/1440
12/1440
60 11h/12h/13h 60Nozzles
Case of Driver microweave mode Color Mode Black Image Only
Mode ESC ( D ESC i ESC(e Used Nozzle number
(H x V) h / r v / r mH*256+mL
n2
360x180
4/1440
12/1440
60 11h/12h/13h 60Nozzles
*1 ) The first nozzle data of each color must be zero
2. Case of printer microweave mode
No support.
[Initial State] -
[Related Commands]
[Setting] Commands whose settings are affected by this command.
The Resolution set of Raster image exerts the influence on the processing by the ESC i
command .
[Setting] Commands that change the effects of this command.
The Resolution setting of Raster image is returned to the initial states by the ESC @ and
the ESC (G commands.
[Operation] Commands whose functionality is affected by this command.
None
[Operation] Commands that change the effects of this command.
None
