***The parameter using high speed black printing in color non M/W mode.
Black mode(using 180 nozzles)
HEAD Printing image
#1
r = 00H (black)
#180
This black print mode using black head 180 full nozzles.
Color mode(using each 60 nozzles) *
HEAD
#1 #1
r = 04H (yellow)
#60 #60
#61 #1
r = 01H (magenta)
#60
#120
#121 #1 r =02H (cyan)
#180 #60
Full nozzles(180 nozzles) print is not supported.
Each of the first nozzle data must be zero
Color mode Black image only (Total 180 nozzles)
HEAD
#1
r = 06H (black3)
#60
r = 05H (black2)
#120
r = 00H (black)
#180
Full nozzles(180 nozzles) print is not supported.
To utilize all 180 black nozzle, combination of Black, Black2, and Black3 must be used.
Data start point (d1)
Data end point (dk)
Data end point (dk)
Data start point (d1)
Data end point (dk)
Data end point (dk)
Data end point (dk)
Data start point (d1)
Data start point (d1)
Data start point (d1)
Data start point (d1)
Data start point (d1)
Data end point (dk)
Data end point (dk)
Data end point (dk)
r = 00 H (black )
Data star
t point (d1)
