LQ-2180 Revision A
Appendix EEPROM Address Map 48
Table 7-3. EEPROM Address Map (3/7) Table 7-4. EEPROM Address Map (4/7)
Address Data Data Format
Q-pit
data
Factory
setting
1DH Pitch selection
0: 10 cpi
1: 12 cpi
2: 15 cpi
3: 17 cpi
4: 20 cpi
5: Proportional
00H
(10 cpi)
00H
(10 cpi)
1EH (reserved) 00H 00H
1FH Print direction
setting
0: Bi-d.
1: Uni-d.
2: Auto
00H
(Bi-d.)
00H
(Bi-d.)
20H I/F mode selection
0: Auto I/F selection
1: Parallel I/F
2: Type-B I/F
00H
(Auto)
00H
(Auto)
21H Auto I/F wait time
setting
10:10 sec.
30:30 sec.
00:10 sec. (the default)
0AH
(10 sec.)
0AH
(10 sec.)
22H Auto line feed
Auto tear off
Skip over
perforations
High speed draft
Input buffer
---
---
---
b0: Auto line feed
0: Off, 1: On
b1: Auto tear off
0: Off, 1: On
b2: Skip over perforation
0: Off, 1: On
b3: High speed draft
0: On, 1: Off
b4: Input buffer
0: On, 1: Off
b5: (reserved)
b6: (reserved)
b7: (reserved)
00H 00H
Address Data Data Format
Q-pit
data
Factory
setting
23H Software
0 slash
Buzzer
Roll paper
Auto CR
A. G. M.
---
---
b0: Software
0: ESC/P2,
1: IBM 2391 Plus
b1: 0 slash,
0: Off, 1: On
b2: Buzzer
0: On, 1: Off
b3: Roll paper
0: Off, 1: On
b4: Auto CR (IBM)
0: Off, 1: On
b5: A. G. M. (IBM)
0: Off, 1: On
b6: (reserved)
b7: (reserved)
00H 00H
24H,
25H
Tear-off
adjustment value
-128 to +127 (by 1/360 inch) 0000H 0000H
26H Other font
selection
0: Roman
1: Sans Serif H
2: OCR-B
3: Orator
4: Orator-S
5: Script C
00H 00H
27H Backup flags 1
Copy mode
00H 00H
28H Backup flags 2
In tear-off state
Bin select
0: Friction Bin 1 or Tractor not
Tear off
1: Friction Bin 1
2: Friction Bin 2
3: Friction Card
4: Tractor & Tear off
00H 00H
