2. Installation
RC180 Safety and Installation Rev.18
36
G6
To carry the Manipulator, have two or more people to work on it and secure the
Manipulator to the delivery equipment or hold the areas indicated in gray in the
figure (bottom of Arm #1 / bottom of the base) by hand. When holding the
bottom of the base by hand, be very careful not to get hands or fingers caught.
Table Top Mounting
G6-45**/G6-55**
Approx. 27 kg: 60 lb.
G6-65**
Approx. 28 kg: 62 lb.
Wall Mounting
G6-45**W/G6-55**W
Approx. 29 kg: 64 lb.
G6-65**W
Approx. 29.5 kg: 65 lb.
Ceiling Mounting
G6-45**R/G6-55**R
Approx. 27 kg: 60 lb.
G6-65**R
Approx. 28 kg: 62 lb.
To Next Page
