Maintenance 8. Maintenance Parts Replacement Procedures
RC700 Series Maintenance Rev.3 63
DMB
-Sub Board
Installation
(1)
Mount the plate
that secures the connectors on the front side to the DMB-
SUB board.
(2)
Mount the DMB
-SUB Board to the DMB. (Mounting screws ×3)
(3)
Connect the cables to the DMB
-SUB Board.
(4)
Mount the Top Panel. (Mounting screw
×6)
(5)
Set
the Encoder Voltage Adjustment Switch.
Set the Encoder Voltage Adjustment Switch according to the length of the M/C cable.
Switch
Length of M/C Cable
1
3 m
2
5 m
3
10 m
4
15, 20 m
(6)
Connect the power plug
. Turn ON the Controller and make sure that the Controller
starts properly without any vibration or abnormal noise.
