Epson RX8111CE User Manual

RX8111CE
Page − 19
ETM61E-01
Table 12 Register Initial value (2)
Address
Function
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
30h
No Function
0
0
0
0
0
0
0
0
31h
No Function
0
0
0
0
0
0
0
0
32h
Power Switch Control
0
0
0
0
0
1
0
0
33h
EVIN Monitor
0
X
0
0
0
0
0
0
34h
Time Stamp Control 1
0
0
0
0
0
0
0
0
35h
Time Stamp Control 2
0
0
0
0
0
0
0
0
36h
Time Stamp Control 3
0
0
0
0
1
1
1
1
37h
No Function
0
0
0
0
0
0
0
0
38h  3Dh
No Function
0
0
0
0
0
0
0
0
3Eh
No Function
X
X
X
X
X
X
X
X
3Fh
TEST
0
0
0
0
0
0
0
0
Address
Hex
Function
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
40, 50, 60, 70
Time Stamp 1/256S
X
X
X
X
X
X
X
X
41, 51, 61, 71
Time Stamp SEC
X
X
X
X
X
X
X
X
42, 52, 62, 72
Time Stamp MIN
X
X
X
X
X
X
X
X
43, 53, 63, 73
Time Stamp HOUR
X
X
X
X
X
X
X
X
44, 54, 64, 74
Time Stamp WEEK
X
X
X
X
X
X
X
X
45, 55, 65, 75
Time Stamp DAY
X
X
X
X
X
X
X
X
46,56, 66, 76
Time Stamp Year
X
X
X
X
X
X
X
X
47,57, 67, 77
Status Stamp
X
X
X
X
X
X
X
X
48, 58, 68, 78
Time stamp 1/256S
X
X
X
X
X
X
X
X
49, 59, 69, 79
Time Stamp SEC
X
X
X
X
X
X
X
X
4A, 5A, 6A, 7A
Time Stamp MIN
X
X
X
X
X
X
X
X
4B,5B, 6B, 7B
Time Stamp HOUR
X
X
X
X
X
X
X
X
4C,5C, 6C, 7C
Time Stamp DAY
X
X
X
X
X
X
X
X
4D,5D, 6D, 7D
Time Stamp MONTH
X
X
X
X
X
X
X
X
4E,5E, 6E, 7E
Time Stamp YEAR
X
X
X
X
X
X
X
X
4F,5F, 6F, 7F
Status Stamp
X
X
X
X
X
X
X
X
X : Undefined. 0 or 1
0 : Reset state
1 : Set state
