Setting Item Setting Explanation
Print Head Alignment Do adjustments when print results appear grainy or unfocused (lines are
misaligned, small text is uneven).
This adjustment adjusts small misalignments in the positions that ink is
output during bi-direction printing. In the following situations, print
results are not improved even if you do these adjustments.
❏ Print Direction is set to Uni-Direction (Low Speed) in Garment
Creator for SC-F3000 Series, the specialized software for the printer.
❏ When doing repeat printing or printing from a USB memory, Current
Settings - Head Move Direction is set to Uni-Directional.
See the following for more details.
U “Execute Print Head Alignment” on page 128
Standard -8 to +8
Micro Adjust -10 to +10
Media Feed Adjust‐
ment
-1.00 to 1.00% Do this adjustment when horizontal stripes (banding) appear in the print
results.
Use this adjustment to adjust how far (width) the platen feeds between
each movement of the print head.
When the banding colors are dark, change the values to the + side; when
the colors are faint (whitish), change them to the - side. First set 0.1% (or
-0.1%), and check the printout, then do further adjustments as needed.
Read the following before doing these adjustments.
U “Precautions when executing Print Adjustments” on page 127
Media Management
SC-F3000 Series User's Guide
Control Panel Menu
117
