D Pressure rollers
These rollers press down on the media during printing.
U “Daily Cleaning” on page 59
E Platen
This suctions and fixes the media for smooth printing and media feeding.
U “Daily Cleaning” on page 59
F Caps
Except during printing, these caps cover the print head nozzles to prevent them drying out. Clean at least once
a month.
U “Cleaning Around the Caps” on page 63
G Wiper unit
The wiper removes ink from the surface of the print head nozzles. The wiper unit is a consumable item.
Replace when a message is displayed on the control panel prompting you to do so.
U “Replacing the Head Cleaning Set” on page 75
H Flushing pad
Ink is discharged onto this pad during flushing. This is a consumable; Replace the wiper unit at the same time.
U “Replacing the Head Cleaning Set” on page 75
Back
A Drive switch
The drive switch is used to feed the media during loading and to rewind the media for replacement.
SC-F9300 Series User's Guide
Introduction
10
