F
Remove film b from the printer.
Note:
Without leaving any creases, store films a and b
together with the counterweight. If you plan on
using the films again, remove dust, etc., and
stretch it well before use.
G
Loosen the roll core holder locking screw on
the left side, and then move both roll core
holders inward.
H
Turn the cover in the illustration below to close
it, and then tighten the screw.
SC-F9300 Series User's Guide
Appendix
128
