The gray area in the illustration below shows the printable area. The arrow indicates the feed direction.
* When Media Size Check is set to Off, this is 1,626 mm (64 inches) regardless of the width of the loaded media.
A to D indicates the margins on all four sides. See the following for more details.
Margin
Position
Explanation Available
Setting
Range
A Rear
*1, *2
This can be set in RIP. To maintain media feeding accuracy, if the settings are less than
5 mm or more than 17 mm, the settings are switched to 5 mm and 17 mm respectively.
5 to 17 mm
B Leading
edge
*1
This can be set in RIP. Differs by the length the media was pulled when the media is
loaded. For continuous printing, although the margins set in RIP are added, to
maintain media feeding accuracy, if the setting is less than 5 mm the setting is
switched to 5 mm.
5 mm or more
C Left edge
*3, *4
The value selected for Side Margin(Left) in the printer's setup menu. The default setting
is 5 mm.
3 to 25 mm
D Right
edge
*3, *4
The total of the values selected for Print Start Position and Side Margin(Right) in the
printer's setup menu. The default setting for Print Start Position is 0 mm and Side
Margin(Right) is 5 mm.
3 to 825 mm
*1 The set margin and the actual print results may differ depending on the RIP being used. Contact the RIP
manufacturer for more information.
SC-F9300 Series User's Guide
Basic Operations
53
