Basic Information Regarding the
Spectrophotometer
Part Names
A Enter button Press this button to measure color. When a menu is selected, this also confirms the
selected item.
B Light The status of the light (on, off. and the color) indicates the status of the
spectrophotometer.
U “Understanding the Status of Color Measurement from the Light and Buzzer”
on page 13
C Navigation button Press these buttons to switch the screen display or select an item. The functions of
the navigation buttons depend on the rotation of the screen.
D Power button Turns the power on and off.
SD-10 User's Guide
Basic Information Regarding the Spectrophotometer
12
