Epson SD-10 - External Dimensions Specifications; Electrical Specifications; Spectrophotometer Electrical Specifications

Color measurement
accuracy
Inter-instrument
agreement
0.4 or less Δ E00 average
1.0 or less Δ E00 maximum
❏ Deviation from SD-10 manufacturing standard for 12 BCRA color
tiles (D50, 2˚)
❏ Ambient temperature 23˚C (73.4˚F), humidity 50%
Short term
repeatability
0.1Δ E94 White
❏ Average of 10 measurements every 3 seconds on white tile (D50,
2˚)
❏ Ambient temperature 23˚C (73.4˚F), humidity 50%
Color difference from
BCRA tile calibration
value
1.0 or less Δ E00 average
❏ Deviation from the color measurement value for 12 BCRA color
tiles (D50, 2 ˚) using a measuring instrument traceable to the
national measurement standards
❏ Ambient temperature 23˚C (73.4˚F), humidity 50%
Interface
*1
USB 2.0 (Full speed USB) USB Type-C connector
Bluetooth Low Energy (Bluetooth Class 2)
*1 Simultaneous use (simultaneous access) of USB and Bluetooth connections is not supported.
c
Important:
Use the device at an altitude of 2,000 m (6,562 ft) or less.
External Dimensions Specifications
External Dimensions Width: 35 mm (1.4 inches)
Depth: 80 mm (3.1 inches)
Height: 77.6 mm (3.1 inches) (sensor cover open), 80 mm (3.1 inches)
(sensor cover closed)
Mass Approx. 190 g (0.42 lb)
Electrical Specifications
Spectrophotometer Electrical Specifications
DC input voltage 5 V
DC input current 0.9 A
SD-10 User's Guide
Specifications
45
