I
Press the enter button.
J
The comparison results between the comparison source (reference) color and the measured color are
displayed. After that, the next color measurement screen is displayed.
A Displays when the compared color measurement value is less than or equal to the Passing Value. Displays
when it is greater than the Passing Value.
B The color being measured is displayed around the edges.
C The color inside the square changes to the color to be measured and compared next.
If the color measurement result is or , the source data automatically moves to the next color in the
sequence. Place the device on the next item to be measured, and then press the enter button. If you want to
measure a color again, use the navigation button to move the focus to the previous reference color, and then
measure the color again.
SD-10 User's Guide
Comparison (Spot) Mode
25
