DISASSEMBLY/ASSEMBLY Removing Board 41
Confidential
A D J U S T M E N T
R E Q U I R E D
After replacing the Main Board, perform the following adjustment.
(Refer to Chapter 5
“ADJUSTMENT”)
1. “EEPROM data copy” (only after replacement)
2. “Destination Setting” (only after replacement*)
3. “USB ID Input” (only after replacement*)
4. “Waste Ink Pad Counter” (Ink Pads must be replaced)
5. “Head ID Input” (only after replacement*)
6. “TOP Margin Adjustment” (only after replacement*)
7. “First Dot Adjustment” (only after replacement*)
8. “Head Angular Adjustment” (only after replacement*)
9. “Bi-D Adjustment” (only after replacement*)
10. “PF Band Adjustment” (only after replacement*)
11. “CR Heat Protection Control” (only after replacement*)]
Note * : (EEPROM Copy NG)
