Epson Stylus C58 User Manual

Epson Stylus C58/C59/ME 2/C79/D78/C90/C91/C92/D92/T20/T20E/T23/T26/S20/T10/T11/ME 30/T21/T24/T27/S21 Revision E
OPERATING PRINCIPLES Printer Mechanism 25
Confidential
2.2.4 Ink System Mechanism
The Ink system mechanism consists of pump mechanism and capping mechanism that
includes wiper mechanism.
2.2.4.1 Pump Unit Mechanism
When the PF motor turns, power is always transmitted to the ink system.
Note * : The PF Motor rotational direction = seen from the left side of the printer.
2.2.4.2 Capping Mechanism
The Capping mechanism covers the printhead with the cap to prevent the nozzle from
increasing viscosity when the printer is in stand-by state or when the printer is off.
Table 2-3. PF Motor Rotational Direction & Ink System Mechanism
Direction* Function
Counterclockwise Absorbs the ink by the Pump Unit
Clockwise Release pump.

Epson Stylus C58 Specifications

General

Printer Type	Inkjet
Max Print Resolution	5760 x 1440 dpi
Print Speed (Black)	17 ppm
Print Speed (Color)	9 ppm
Connectivity	USB
Dimensions (W x D x H)	435 x 219 x 165 mm
Ink Palette Supported (Colors)	Cyan, Magenta, Yellow, Black
Total Media Capacity	100 sheets
Operating System Compatibility	Windows, Mac
Paper Sizes Supported	A4, A5, B5
Weight	2.8 kg
Media Type	Plain paper, Photo paper, Envelopes
Ink Cartridges	Individual ink cartridges
