External Dimensions and Necessary Space
External dimensions (When the sorter unit is installed)
From above (Dual Roll Model)
From above (Single Roll Model)
Units: inches (mm)
Units: inches (mm)
44.57 (1132)
3.94
(100)
64.25 (1632)
3.94
(100)
45.47 (1155) 27.56 (700)
76.97 (1955)
12.80
(325)
15.75 (400)
19.37 (492)
76.97 (1955)
45.47 (1155)
3.94
(100)
44.57 (1132)
3.94
(100)
64.25 (1632)
15.75 (400)
17.99 (457)
27.56 (700)
