Setup and Maintenance
88
D
Check the status of each head displayed in Result.
When the nozzles are cleared, "Good" is displayed.
If nozzles are clogged, a message is displayed that indicates you need to clean the Print Head Unit again.
Perform necessary cleaning.
Reading the Results:
When you want to confirm the clogged nozzles by looking at the prints, perform Print Check Pattern from Nozzle
Check (0312).
U “Nozzle Check” on page 89
Color Explanation
Green The nozzles are not clogged.
Yellow Clogging is detected.
Perform Auto Cleaning (0311) again.
Red Clogging is detected.
Perform Detect Clogging from Nozzle Check (0312), and then perform Powerful
cleaning again for heads indicated by red.
White Auto Cleaning is still in progress.
To Next Page
