Appendix
95
Place your hands at the points indicated in the photo, and then lift.
Printer Specifications
c
Important:
■ Only hold the required area. Otherwise, it may breakdown.
■ Move the printer with ink cartridges installed. Do not remove the ink cartridges; otherwise, the nozzles may be
clogged and make it impossible to print, or ink may leak.
■ When moving the printer, do not tilt it. Ink could leak out.
Basic specifications
Printing method On-demand ink jet
Nozzle configuration 180 nozzles for each color
Print direction Bidirectional printing
Highest resolution 1440 x 720 dpi
Paper feed method Friction feed
Interface Universal Serial Bus Specifications Revision 2.0
Electrical Specifications
Rated voltage AC 100 to 120 V AC 220 to 240 V
Rated frequency range 50/60 Hz 50/60 Hz
Rated current 3.0 A 1.5 A
To Next Page
