A-2 Product Specifications of the TM-C100 Rev. C
Vibration resistance test
specifications:
Packaged: Frequency 5 to 55 Hz
Acceleration approximately 19.6 m/s
2
{2 G}
Sweep 10 minutes (half cycle)
Time 1 hour
Orientation XYZ
No external or internal damage was observed and no problems
occurred in operation after vibration under the above conditions.
Shock resistance test
specifications
Packaged:
Unpacked:
Packaging specification Epson standard package
Height 60 cm
Orientation 1 corner, 3 edges, and 6 surfaces
Height 5 cm
Orientation Lift one edge and release it (for all 4 edges).
No external or internal damage was observed and no problems
occurred in operation after dropping.
Noise Operating approximately 51 dB (ANSI bystander position)
(including using the autocutter in normal mode printing)
Item Specification
