2-6 Setup Rev. C
2.3 Printer Setup
2.3.1 Installing options
❏ When using the ASF (auto sheet feeder) specification printer, see "Installing the ASF (auto
sheet feeder) unit" on page 2-6.
❏ When using the roll paper specification printer, see "Installing the roll paper holder" on page
2-8.
2.3.1.1 Installing the ASF (auto sheet feeder) unit
1. Check that the printer is not connected to the AC adapter. If the printer is on, turn it off and
remove the AC adapter.
2. Pass the cable of the auto sheet feeder through the groove in the auto sheet feeder.
3. Insert the hooks of the auto sheet feeder into the slots in the top of the printer at the back.
Note:
Take care not to catch the cable of the auto sheet feeder between the printer and the auto sheet feeder.
groove
insert the hook
in the slot
To Next Page
