Reference Information 4-3
Paper Specifications
Paper feed method:
Friction feed
Paper feed pitch:
Default 4.233 mm (1/6 inch)
Can be set in units of 0.176 mm (1/144
inch) by the
ESC 2
and
ESC 3
commands.
Paper feed speed:
Approximately 25 lines/second (4.17
inches/second) (continuous feeding)
Paper size and weight: Normal paper (single-ply)
Size: Width 76 mm ± 0.5 mm
(3.0" ± 0.02")
Maximum
outside
diameter:
83 mm (3.27")
Core: Paper rolls that have the
paper glued or taped to
the core can cause a paper
jam. If you use a paper
roll with the paper glued
or taped to the core, be
sure to use the optional
near end detector.
Thickness: 0.06 to 0.085 mm (.0024 to
.0033")
Weight: 52.3 to 64.0 g/m
2
(13.9 to
17 lbs) (45 to 55 Kg (20.41
to 24.94 lbs)/1000 sheets/
1091 mm
✕
788mm
(43.00"
✕
31.02")
