Disassembly/Reassembly Disassembly/Reassembly Procedures 28
WF-2540 / WF-2530 / WF-2520 / WF-2510 / WF-2010 series Revision B
2.2.2 Disassembly Flowchart
WF-2540 / WF-2530 / WF-2520 / WF-2510 / WF-2010 series described in this manual have differences in their
structure because the same printer mechanism is used for some of them and the composition of housings or
functions differs.
The functions and differences according to the models are as follows.
Therefore, parts and units are colored and classified into 2 types in the flowchart given in this section.

Common parts/unit: Black
 Model-specific parts/unit: Red
Table 2-2. Function List According to Models
Item
Multifunction Printer Singlefunction Printer
WF-2540
Series
WF-2530
Series
WF-2520
Series
WF-2510
Series
WF-2010
Scanner
Compatible O O O O ---
Non-compatible --- --- --- --- O
ADF
Compatible O O O --- ---
Non-compatible --- --- --- O O
Panel
2.5 inch LCD type O --- --- --- ---
2Line Bitmap type --- O O O ---
LED & Button type --- --- --- --- O
FAX OOOO ---
Wireless LAN O O --- O O
Ethernet O --- O --- O
USB O --- --- --- ---
Disassembly Flowchart
Start Position
p 30 p 30 p 30 p 30 p 32
Table 2-3. Components According to Functions
Item Specification
Scanner
The following part is not mounted on the models without the Scanner.
• Scanner Unit
• Main Board FFC Holder
ADF
 The ADF Unit is not mounted on the models without the ADF.
 The Document Cover Assy is mounted on the models without the ADF instead of the ADF Unit.
Panel
The shape and unit of components below differ due to the difference of specifications of Panel.
• Panel Unit
• Main Board
• Shield Plate
FAX The FAX Assy is not mounted on the model without the FAX.
Wireless LAN The Wireless LAN Module is not mounted on the models without the Wireless LAN.
Ethernet
 The Ethernet Board Assy is not mounted on the models without the Ethernet.
 The shape and unit of components of the Housing Left Assy differ due to the support/unsupport of the
Ethernet.
USB The USB Board is not mounted on the models without the USB.

Epson WF-2010 Specifications

General

Print Technology	Inkjet
Print Resolution	5760 x 1440 dpi
Paper Capacity	100 sheets
Duplex Printing	Manual
Functions	Print
Print Speed (Color)	18 ppm
Connectivity	USB, Wi-Fi
Supported Paper Sizes	A4, A5, A6, B5
