Adjustment Details of Adjustments 77
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
Figure 3-30. Touch Panel Adjustment (2)
4. Press “Push this Area.[OK]” to displayed the adjustment screen. To abort the adjustment, press “Push this
Area.[Cancel]”.
Figure 3-31. Touch Panel Adjustment (3)
5. Press “+” displayed on the four corners in order using the touch pen.
Figure 3-32. Touch Panel Adjustment (4)
6. When preforming the adjustment again, press “Push this Area.[Cancel]” and start from Step 2 again. To save
the adjustment result, press “Push this Area. [Save]”.
Figure 3-33. Touch Panel Adjustment (5)
Touch Panel to coordinate them.
Push this Area. [OK]
Push this Area. [Cancel]
+ << Please Touch
Calibration Check
Push this Area. [Save]
Push this Area. [Cancel]

Epson WF-5690 Series Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Fax	Yes
Functions	Print, Copy, Scan, Fax
Dimensions (W x D x H)	18.1" x 25.8" x 15.1"
Print Technology	PrecisionCore
Print Speed (Black/Color)	20 ppm / 20 ppm
Scanner Type	Flatbed, ADF
ADF Capacity	35 sheets
Display	4.3" color touchscreen
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Paper Sizes	A4, A5, A6
Ink Cartridges	Black, Cyan, Magenta, Yellow
Monthly Duty Cycle	45, 000 pages
