Epson WF-7720 Series - Control Panel

A
Scanner unit Scans placed originals. Open when replacing ink cartridges or
removing jammed paper inside the printer.
B
Ink cartridge cover Open when replacing ink cartridges.
C
Ink cartridge holder Install the ink cartridges. Ink is ejected from the print head nozzles
underneath.
A
Rear cover 2 Remove when removing jammed paper.
B
Rear cover 1 Open when replacing the maintenance box or removing jammed
paper.
C
AC inlet Connects the power cord.
D
LINE port Connects a phone line.
E
EXT. port Connects external phone devices.
F
LAN port Connects a LAN cable.
G
USB port Connects a USB cable.
