Epson XP-420 SERIES User Manual

❏ ere are broken lines or missing segments: e print head nozzles may be clogged. Go to the next step.
Note:
e test pattern may vary by model.
7. Select Ye s using the d or u button, and then press the OK button.
8. Follow the on-screen instructions to clean the print head.
9. When cleaning is nished, select Nozzle Check using the
d or u button, and then follow the on-screen
instructions to print the nozzle check pattern again. Repeat cleaning and printing the pattern until all lines are
printed completely.
Related Information
&
“Loading Paper in the Rear Paper Feed” on page 23
Checking and Cleaning the Print Head - Windows
1. Load A4-size plain paper in the printer.
2. Access the printer driver window.
3. Click Nozzle Check on the Maintenance tab.
4.
Follow the on-screen instructions.
Related Information
& “Loading Paper in the Rear Paper Feed” on page 23
& “Windows Printer Driver” on page 78
Checking and Cleaning the Print Head - Mac OS X
1. Load A4-size plain paper in the printer.
2.
Select System Preferences from the
menu > Printers & Scanners (or Print & Scan, Print & Fax), and
then select the printer.
3.
Click Options & Supplies > Utility > Open Printer Utility.
4.
Click Nozzle Check.
5. Follow the on-screen instructions.
User's Guide
Improving Print and Scan Quality
73

Epson XP-420 SERIES Specifications

General

Print Technology	Inkjet
Max Print Resolution	5760 x 1440 dpi
Connectivity	Wi-Fi, USB
Scanner Type	Flatbed
Max Scan Resolution	1200 x 2400 dpi
Display	2.5" color LCD
Printer Type	All-in-One
Functions	Print, Scan, Copy
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Input Paper Capacity	100 sheets
Paper Sizes	Letter, Legal, Envelopes
Operating System Support	Windows, Mac
Print Speed Black	9 ppm
Print Speed Color	4.5 ppm
Weight	9 lbs
Ink Cartridges	4 (Black, Cyan, Magenta, Yellow)
