Erchonia EVRL - EVRL Interface Navigation; EVRL Touchscreen Interaction; Device Access: Passcode and Mode Selection

Page 12
ERCHONIA® EVRL™ PROPER USE REFERENCE GUIDE
STEP #1 “Passcode Screen”
Enter the passcode “1234” (factory set code), then press
the “SIGN IN” icon.
STEP #2 “Function Screen”
a) “Mode Select” icon
b) “Settings” icon: Not used in this clinical trial.
c) “Device Info” icon: Not used in this clinical trial
To proceed to the neuropathy foot pain treatment, press
the “MODE SELECT” icon (ITEM #2)
STEP #3 “Mode Select Screen”
a) “User Protocol Mode” icon
To proceed to the neuropathy foot pain treatment, press the
“User Protocol Mode” icon (ITEM #3).
Password Screen
Function Screen
ITEM #2
Mode Select Screen
ITEM #3
