The CF3 explained
Flip Head saddle outer clamps (L/R)
Flip Head saddle inner clamps (L/R)
Leaf spring “Back”
Leaf spring “Front”
Saddle clamping screws
Lock screw with washer
Fig: Diagram CF3 Pro Carbon
A CF3 seatpost is comprised of two leaf springs arranged in parallel. Unevenness
in the road surface causes small impacts which the leaf springs absorb by flexing
backwards. The leaf springs are made up of 19 layers of high performance
composite. This construction makes for extremely sensitive shock absorption
which is a significant advance in telescopic seat post design.
