Do not use any other seatpost shims other than the one provided with
the post, and only one such shim may be used. Any other type of shim
may cause a failure of the post and an injury.
Make a note of the chosen saddle angle ‘a’ (details on page 49) and the
seatpost extension ‘b’ (details on page 51) (Fig. A). Undo the seat tube clamp
and remove the seatpost from the bike frame (Fig. B).
Anti-Slip Shim
Fig. A: Make a note of saddle angle ‘a’ and
seatpost extension ‘b’.
Fig. B: Loosen the seatpost clamp.
a
b
