Insert the seatpost into the frame. The back of the post is clearly marked “Back”.
Try to minimize twisting as you fit the seat post (Fig. C). Tighten the seatpost
clamp just enough so that the seatpost does not slide into the frame during the
remaining setup steps. (Fig. D).
Only tighten up the seatpost binder bolt fully after the seat height and tilt
adjustment has been completed. Do not sit on the saddle or ride off
before all bolts are fully torqued.
Fig. C: Use very minimal twisting motions to fit
the seatpost into the frame.
Fig. D: Tighten the seatpost clamp loosely to
prevent the post slipping into the frame.
Tighten loosely
Twist minimally so as
to avoid scoring and
damaging the post.
