ermaf TR 75 - Technical Data; Declaration of Conformity

GB-27
D
GB
F
NL
I
E
Technical data
Gas types: II2ELL3B/P,
natural gas H and L (gases of category2);
LPG, gaseous (gases of category3): propane,
propane/butane, butane.
Fused with 10A.
NOx Class: depending on gas type up to Class 5.
Inlet pressure p
u
: 20 to 70mbar.
Resistant to high-pressure cleaning.
Gas connection: Rp¾ to ISO7-1.
Staged control: On/Off signal (240VAC or
24VAC/DC via coupling relay).
Continuous control: capacity control from
60 – 100% (0 – 10 V/0 – 20 mA actuating signal).
Efficiency: 75 kW = 92%, 45 kW = 98%.
Burner control unit with direct spark ignition and
ionization control.
Fan type:
main fan: axial, burner fan: radial.
Material:
housing: stainless steel,
heat exchanger: stainless steel,
burner control unit: flame-retardant polymer blend
made of polycarbonate (PC) and acrylonitrile
butadiene styrene copolymer (ABS).
Ambient temperature T
max
: ≤ 40°C,
temperature differential ∆T
max
: ≤ 35°C,
example for calculating the temperature of
emissions:
T + ∆T = 40°C + 35°C = 75°C.
No condensation permitted.
Cycle lock: 15s.
Capacity: 45 – 75 kW.
Jet length: >50 m,
velocity at the jet end: 0.5m/s.
Gas consumption:
natural gas L: 8.75 m
3
/h,
natural gas H: 7.52 m
3
/h,
propane: 5.82 kg/h,
butane: 5.91 kg/h.
Connection rating:
400VAC, -15/+10%, 50Hz, 1022W.
Current consumption: I
N
: 2.3 A.
Air circulation:
controlled air flow: ±7000 m
3
/h,
heating: ±8000 m
3
/h.
Dimensions: 2145 x 811 x 653 mm.
Sound level: ≤68dB.
Weight: 130 kg.
Declaration of conformity
We, the manufacturer, hereby declare that the prod-
uctTR complies with the requirements of the listed
Directives:
– 2009/142/EC
– 2006/95/EC
– 2004/108/EC
The relevant product corresponds to the type tested
by the notified body 0085. The production is subject
to the surveillance procedure pursuant to annexII,
paragraph3 of Directive 2009/142/EC, Deutscher
Verein des Gas- und Wasserfaches e.V. (German
Technical and Scientific Association for Gas and
Water, DVGW), Notified Body 0085.
Elster-Instromet B.V.
Scan of the Declaration of conformity (D, GB) – see
www.docuthek.com
