* Continuous Mode Output Format
Protocol: 9600 baud, 8 data bits, 1 stop bit, no parity (9600-8-N-1) ( Default )
Data: (8 characters)
Character Açıklama
1. character
A
stable, no tare
B
stable, have tare
C
no stability, no tare
D
no stability, have tare
E
underload / overload
2-7. characters 1 2 3 4 5 6
display value with 6 digits ASCII, no decimal point, no
unit (e.g. ' 1500')
8. character
↵
Carriage Return (ASCII 13)
* Terminal Mode Output Format
9600 baud, 8 data bit, 1 stop bit, no parity (9600-8-N-1)
In this mode, the indicator responds to specific commands via the serial interface. The commands and
the responses are as below :
Command Response
d ↵
Sends the indication value as seen in the display in the
form of continuous mode protocol
z ↵ Zero Key
No response
t ↵ Tare Key
No response
p ↵ Print Key
Outputs weighing result in COM1 alibi record output format
if saving is successful.
v1.00 Page 16
